Features
Specification
| Maximum capacity (Emax) | kg | 100, 200,300 | 500, 750, 1000, 1500, 2000 |
| Rated output (Cn) | mV/V | 2.0±0.003 | |
| Accuracy | ±%FS | 0.05 | |
| Max. number of intervals (nLC) | - | 3000 | |
| Creep (30 minutes) | ±%FS | 0.024 | |
| Zero balance | ±%FS | 1 | |
| Temperature effect on zero balance (TCO) | ±%FS/10°C | 0.02 | |
| Temperature effect on sensitivity (TC Span) | ±%FS/10°C | 0.02 | |
| Safe overload | %FS | 120 | |
| Ultimate overload | %FS | 180 | |
| Nominal temperature range | °C | -10 ... + 40 | |
| Operating temperature range | °C | - 30 ... + 70 | |
| Input impedance | Ω | 400 ± 20 | |
| Output impedance | Ω | 352 ± 3 | |
| Insulation impedance | MΩ | ≥ 5000 | |
| Recommended excitation | V DC/AC | 10 - 12 | |
| Excitation maximum | V DC/AC | 15 | |
| Material | - | Alloy steel | |
| Protection class | - | IP67 | IP68 |
| Cable | - |
Length: 3m, or customize special length to order; Diameter: Φ 5mm |
|
Wiring
The load cell is provided with a shielded 4 or 6 conductor cable. The shield will be connected or not connected to the load cell according to customer’s preference.
Dimension
Dimension unit: mm
| Capacity (kg) | H |
| 100, 200, 300, 500 | 15.9 |
| 750, 1000 | 19.1 |
| 1500, 2000 | 25.4 |
Accessories
N/A
